Powermatic PM2820EVS 1HP 20” Variable Speed Drill Press

A geared drivetrain and two variable speeds ranging from 150 to 3600 RPM give the Powermatic PM2820EVS versatility not found in competing drill presses. Whether you use the low- or the high-speed range, the electronic variable speed ensures that no torque is lost. The PM2820EVS features one of the most versatile tables on the market, measuring a full 20-1/2” x 15-1/2” in size, with a large removable cast iron insert that lets you drill tall, bulky workpieces by feeding them through the bottom of the table. The table tilts left and right a full 90°, useful for drilling at extreme angles, and also for drilling into the end grain of long stock. The high-visibility laser pinpoints the exact drilling location, while the included fence and stop make production drilling ultra-efficient. Handles can be installed on the left or right according to your preference. Integrated LED light reduces shadows for optimal visibility.

Features:

• Gear driven power transfers torque consistently and efficiently for a wide range of materials
• Electronic variable speed means torque is not lost using either the higher or low speed settings
• Low speed setting ranges from 150 to 870 RPM; high speed setting ranges from 600 to 3600 RPM
• Easily visible digital readout gives users optimal control and feedback
• Oversized cast base offers outstanding stability for the 20” swing
• Handles can be reversed for left- or right-handed operation
• Large cast table adjusts to a range of positions and tilts to a full ninety degree position
• Includes the most versatile table on the drill press market—allows insert to be removed for better access to oversized pieces
• Includes Powermatic’s patented integrated depth stop for efficient drilling
• For unbeatable accuracy, the laser cross hairs provide precise tool point indication
